AET 6000系列直流電子負載，可選擇60V,120A或450V,40A兩種機型，並提供最大600W的功率負載。
簡化的操作面板，提供定電壓與定電流操作模式。
輕量化的設計，在600W的功率下全機總重量僅3公斤，機身提供提把，方便攜帶與測試。
可以支援多種配件以對應不同的測試環境與應用 :
搭配電池配件，可應用於EMI測試環境
搭配USB配件，可應用於電池或系統化測試 (架構中…)
搭配藍芽模組，可應用於遠端遙控環境 (架構中…)
| SPECIFICATIONS | ||
| Model | 60120B | 45040B |
| Power | 600W | 600W |
| Current | 0 - 120A | 0 - 40A |
| Voltage | 0 - 60V | 0 - 450V |
| Min. Operating Voltage (DC) | 1.5V@ 120A | 1.5V@ 40A |
| Constant Current Mode | ||
| Range | 0~120A | 0~40A |
| Resolution | 10mA | 1mA |
| Accuracy | 0.025% (0.5A) | 0.025% (0.5A) |
| 0.025% (10A) | 0.025% (1A) | |
| 0.025% (60A) | 0.025% (20A) | |
| 0.025% (120A) | 0.025% (40A) | |
| Constant Voltage Mode | ||
| Range | 2~60V | 10~450V |
| Resolution | 1mV | 10mv |
| Accuracy | 0.025% (5V) | 0.025% (10V) |
| 0.025% (20V) | 0.025% (200V) | |
| 0.025% (40V) | 0.025% (300V) | |
| 0.025% (60V) | 0.025% (450V) | |
| Measurement Section | ||
| Voltage Read Back | ||
| Range | 0~60V | 0~450V |
| Resolution | 1mV | 10mv |
| Accuracy | 0.1% (0.5V) | 0.1% (0.5V) |
| 0.1% (10V) | 0.1% (100V) | |
| 0.1% (30V) | 0.1% (300V) | |
| 0.1% (60V) | 0.1% (450V) | |
| Current Read Back | ||
| Range | 0~120A | 0~40A |
| Resolution | 10mA | 1mA |
| Accuracy | 0.1% (0.5A) | 0.1% (0.5A) |
| 0.1% (10A) | 0.1% (1A) | |
| 0.1% (60A) | 0.1% (20A) | |
| 0.1% (120A) | 0.1% (40A) | |
| Protective Section | ||
| Over Power Protection | ≒600W | ≒600W |
| Over Voltage Protection | ≒60V | ≒450V |
| Hardware Over Current Protection | ≒132A | ≒44A |
| Software Hardware Over Current Protection | 600W/SourceV = SetI | 600W/SourceV = SetI |
| Over Temperature Protection | ≒85°C | ≒85°C |
| General | ||
| Input Resistance (Load Off) | 200kΩ (Typical) | 200kΩ (Typical) |
| Temperature Coefficient | 50PPM/°C (Typical) | 50PPM/°C (Typical) |
| Power (AC) | 110~240V 1A MAX. | 110~240V 1A MAX. |
| Dimensions (WxHxD) | 142x175x295 mm | 142x175x295 mm |
| Weight | 2.8kg | 2.8kg |
| Operating Range | 0~40°C | 0~40°C |
| EMC & Safety | CE | CE |
